Cyrix-Li-ct 12/24V-120A combiner

SKU: CYR010120412

The Cyrix-Li-ct 12/24V-120A combiner, part number CYR010120412, belongs to the Victron Energy Cyrix Battery Combiners product family.

Pre-configuration + remote commissioning available

Victron with technical support

We do more than supply components. If required, we configure suitable devices before shipping and support you or your installer through remote commissioning.

Show optional services

Pre-configuration before shipping
System design and wiring diagram
Technical support for your local installer
Remote configuration and assisted commissioning
On-site installation / commissioning

Add to request

Technical documentation

Datasheets, manuals and certificates directly from the manufacturer.

Open manufacturer documentation

Description

The Cyrix-Li-ct 12/24V-120A combiner, part number CYR010120412, belongs to the Victron Energy Cyrix Battery Combiners product family.

Technical specifications

Nominal battery voltage	12V or 24V
Current consumption when open	4 mA
Protection category	IP54
Weight	0.11 kg
Height	64 mm
Width	64 mm
Depth	80 mm
Connect Profiles	See our website
Continuous Current1224	120 A
Control Input	The Cyrix engages when the control input is high (appr. Battery voltage) The Cyrix disengages when the control input is left free floating or pulled low
